Realiza una tarea para un cliente, implementa un web service

Tipos

• Un stateless session bean no mantiene un estado conversacional con el cliente
• En un stateful session bean, las instancias de las variables representan el estado de una sesión

Representa un objeto que existe en almacenamiento persistente

• Persistence
• Shared Access
• Primary Key
• Relationships

Tipos

• Container-managed persistence (CMP)
• Bean-managed persistence (BMP)

   1:package com.titan.travelagent;
   2:
   3:import com.titan.cabin.CabinRemote;
   4:import com.titan.cabin.CabinHomeRemote;
   5:import java.rmi.RemoteException;
   6:import javax.naming.InitialContext;
   7:import javax.naming.Context;
   8:import javax.ejb.EJBException;
   9:import java.util.Properties;
  10:import java.util.Vector;
  11:
  12:public class TravelAgentBean implements javax.ejb.SessionBean
  13:{
  14:
  15:   public void ejbCreate()
  16:   {
  17:      // Do nothing.
  18:   }
  19:
  20:   public String [] listCabins(int shipID, int bedCount)
  21:   {
  22:      try
  23:      {
  24:         javax.naming.Context jndiContext = new InitialContext();
  25:         Object obj =
  26:            jndiContext.lookup("java:comp/env/ejb/CabinHomeRemote");
  27:
  28:
  29:         CabinHomeRemote home = (CabinHomeRemote)
  30:            javax.rmi.PortableRemoteObject.narrow(obj,CabinHomeRemote.class);
  31:
  32:         Vector vect = new Vector();
  33:         for (int i = 1; ; i++)
  34:         {
  35:            Integer pk = new Integer(i);
  36:            CabinRemote cabin = null;
  37:            try
  38:            {
  39:               cabin = home.findByPrimaryKey(pk);
  40:            }
  41:            catch(javax.ejb.FinderException fe)
  42:            {
  43:               System.out.println("Caught exception: "+fe.getMessage()+" for pk="+i);
  44:               break;
  45:            }
  46:            // Check to see if the bed count and ship ID match.
  47:            if (cabin != null &&
  48:                cabin.getShipId() == shipID &&
  49:                cabin.getBedCount() == bedCount)
  50:            {
  51:               String details =
  52:                  i+","+cabin.getName()+","+cabin.getDeckLevel();
  53:               vect.addElement(details);
  54:            }
  55:         }
  56:
  57:         String [] list = new String[vect.size()];
  58:         vect.copyInto(list);
  59:         return list;
  60:
  61:      }
  62:      catch(Exception e)
  63:      {
  64:         throw new EJBException(e);
  65:      }
  66:   }
  67:
  68:   public void ejbRemove(){}
  69:   public void ejbActivate(){}
  70:   public void ejbPassivate(){}
  71:   public void setSessionContext(javax.ejb.SessionContext cntx){}
  72:}

   1:package com.titan.travelagent;
   2:
   3:import java.rmi.RemoteException;
   4:import javax.ejb.CreateException;
   5:
   6:public interface TravelAgentHomeRemote extends javax.ejb.EJBHome {
   7:
   8:    public TravelAgentRemote create()
   9:        throws RemoteException, CreateException;
  10:
  11:}

   1:package com.titan.travelagent;
   2:
   3:import java.rmi.RemoteException;
   4:import javax.ejb.FinderException;
   5:
   6:public interface TravelAgentRemote extends javax.ejb.EJBObject {
   7:
   8:    // String elements follow the format "id, name, deck level"
   9:    public String [] listCabins(int shipID, int bedCount)
  10:        throws RemoteException;
  11:
  12:}

   1:package com.titan.cabin;
   2:
   3:import javax.ejb.EntityContext;
   4:import javax.ejb.CreateException;
   5:
   6:public abstract class CabinBean
   7:   implements javax.ejb.EntityBean
   8:{
   9:
  10:   public Integer ejbCreate(Integer id)
             throws CreateException
  11:   {
  12:      this.setId(id);
  13:      return null;
  14:   }
  15:   public void ejbPostCreate(Integer id)
  16:   {
  17:   }
  18:
  19:   public abstract void setId(Integer id);
  20:   public abstract Integer getId();
  21:
  22:   public abstract void setShipId(int ship);
  23:   public abstract int getShipId( );
  24:
  25:   public abstract void setName(String name);
  26:   public abstract String getName( );
  27:
  28:   public abstract void setBedCount(int count);
  29:   public abstract int getBedCount();
  30:
  31:   public abstract void setDeckLevel(int level);
  32:   public abstract int getDeckLevel();
  33:
  34:   public void setEntityContext(EntityContext ctx)
  35:   {
  36:      // Not implemented.
  37:   }
  38:   public void unsetEntityContext()
  39:   {
  40:      // Not implemented.
  41:   }
  42:   public void ejbActivate()
  43:   {
  44:      // Not implemented.
  45:   }
  46:   public void ejbPassivate()
  47:   {
  48:      // Not implemented.
  49:   }
  50:   public void ejbLoad()
  51:   {
  52:      // Not implemented.
  53:   }
  54:   public void ejbStore()
  55:   {
  56:      // Not implemented.
  57:   }
  58:   public void ejbRemove()
  59:   {
  60:      // Not implemented.
  61:   }
  62:}

   1:package com.titan.cabin;
   2:
   3:import java.rmi.RemoteException;
   4:import javax.ejb.CreateException;
   5:import javax.ejb.FinderException;
   6:
   7:public interface CabinHomeRemote extends javax.ejb.EJBHome
   8:{
   9:   public CabinRemote create(Integer id)
  10:      throws CreateException, RemoteException;
  11:
  12:   public CabinRemote findByPrimaryKey(Integer pk)
  13:      throws FinderException, RemoteException;
  14:}

   1:package com.titan.cabin;
   2:
   3:import java.rmi.RemoteException;
   4:
   5:public interface CabinRemote extends javax.ejb.EJBObject
   6:{
   7:   public String getName() throws RemoteException;
   8:   public void setName(String str) throws RemoteException;
   9:   public int getDeckLevel() throws RemoteException;
  10:   public void setDeckLevel(int level) throws RemoteException;
  11:   public int getShipId() throws RemoteException;
  12:   public void setShipId(int sp) throws RemoteException;
  13:   public int getBedCount() throws RemoteException;
  14:   public void setBedCount(int bc) throws RemoteException;
  15:}

   1:package com.titan.clients;
   2:
   3:import com.titan.travelagent.TravelAgentHomeRemote;
   4:import com.titan.travelagent.TravelAgentRemote;
   5:
   6:import javax.naming.InitialContext;
   7:import javax.naming.Context;
   8:import javax.naming.NamingException;
   9:import javax.ejb.CreateException;
  10:import javax.rmi.PortableRemoteObject;
  11:
  12:import java.rmi.RemoteException;
  13:
  14:public class Client_3
  15:{
  16:   public static int SHIP_ID = 1;
  17:   public static int BED_COUNT = 3;
  18:
  19:   public static void main(String [] args)
  20:   {
  21:      try
  22:      {
  23:         Context jndiContext = getInitialContext();
  24:
  25:         Object ref = jndiContext.lookup("TravelAgentHomeRemote");
  26:
  27:         TravelAgentHomeRemote home = (TravelAgentHomeRemote)
  28:            PortableRemoteObject.narrow(ref,TravelAgentHomeRemote.class);
  29:
  30:         TravelAgentRemote travelAgent = home.create();
  31:
  32:         // Get a list of all cabins on ship 1 with a bed count of 3.
  33:         String list [] = travelAgent.listCabins(SHIP_ID,BED_COUNT);
  34:
  35:         for(int i = 0; i < list.length; i++)
  36:         {
  37:            System.out.println(list[i]);
  38:         }
  39:      }
  40:      catch(java.rmi.RemoteException re)
  41:      {
  42:         re.printStackTrace();
  43:      }
  44:      catch(Throwable t)
  45:      {
  46:         t.printStackTrace();
  47:      }
  48:   }
  49:
  50:   static public Context getInitialContext() throws Exception
  51:   {
  52:      return new InitialContext();
  53:      /**** context initialized by jndi.properties file
  54:        java.util.Properties p = new java.util.Properties();
  55:p.put(Context.INITIAL_CONTEXT_FACTORY, "org.jnp.interfaces.NamingContextFactory");
  56:        p.put(Context.URL_PKG_PREFIXES, "jboss.naming:org.jnp.interfaces");
  57:        p.put(Context.PROVIDER_URL, "localhost:1099");
  58:        return new javax.naming.InitialContext(p);
  59:      */
  60:   }
  61:
  62:}
  63:


   1:<?xml version="1.0"?>
   2:
   3:<jboss>
   4:     <enterprise-beans>
   5:       <entity>
   6:         <ejb-name>CabinEJB</ejb-name>
   7:         <jndi-name>CabinHomeRemote</jndi-name>
   8:       </entity>
   9:       <session>
  10:         <ejb-name>TravelAgentEJB</ejb-name>
  11:         <jndi-name>TravelAgentHomeRemote</jndi-name>
  12:         <ejb-ref>
  13:           <ejb-ref-name>ejb/CabinHomeRemote</ejb-ref-name>
  14:           <jndi-name>CabinHomeRemote</jndi-name>
  15:         </ejb-ref>
  16:       </session>
  17:     </enterprise-beans>
  18:</jboss>


   1:<?xml version="1.0"?>
   2:
   3:<!DOCTYPE ejb-jar PUBLIC
   4:"-//Sun Microsystems, Inc.//DTD Enterprise JavaBeans 2.0//EN"
   5:"http://java.sun.com/dtd/ejb-jar_2_0.dtd">
   6:
   7:<ejb-jar>
   8:
   9: <enterprise-beans>
  10:   <entity>
  11:      <ejb-name>CabinEJB</ejb-name>
  12:      <home>com.titan.cabin.CabinHomeRemote</home>
  13:      <remote>com.titan.cabin.CabinRemote</remote>
  14:      <ejb-class>com.titan.cabin.CabinBean</ejb-class>
  15:      <persistence-type>Container</persistence-type>
  16:      <prim-key-class>java.lang.Integer</prim-key-class>
  17:      <reentrant>False</reentrant>
  18:      <cmp-version>2.x</cmp-version>
  19:      <abstract-schema-name>Cabin</abstract-schema-name>
  20:      <cmp-field><field-name>id</field-name></cmp-field>
  21:      <cmp-field><field-name>name</field-name></cmp-field>
  22:      <cmp-field><field-name>deckLevel</field-name></cmp-field>
  23:      <cmp-field><field-name>shipId</field-name></cmp-field>
  24:      <cmp-field><field-name>bedCount</field-name></cmp-field>
  25:      <primkey-field>id</primkey-field>
  26:      <security-identity><use-caller-identity/></security-identity>
  27:   </entity>
  28:
  29:   <session>
  30:     <ejb-name>TravelAgentEJB</ejb-name>
  31:     <home>com.titan.travelagent.TravelAgentHomeRemote</home>
  32:     <remote>com.titan.travelagent.TravelAgentRemote</remote>
  33:     <ejb-class>com.titan.travelagent.TravelAgentBean</ejb-class>
  34:     <session-type>Stateless</session-type>
  35:     <transaction-type>Container</transaction-type>
  36:
  37:     <ejb-ref>
  38:       <ejb-ref-name>ejb/CabinHomeRemote</ejb-ref-name>
  39:       <ejb-ref-type>Entity</ejb-ref-type>
  40:       <home>com.titan.cabin.CabinHomeRemote</home>
  41:       <remote>com.titan.cabin.CabinRemote</remote>
  42:     </ejb-ref>
  43:
  44:     <security-identity><use-caller-identity/></security-identity>
  45:
  46:  </session>
  47: </enterprise-beans>
  48:
  49: <assembly-descriptor>
  50:
  51:   <security-role>
  52:      <description>
  53:         This role represents everyone who is allowed full access to the beans.
  54:      </description>
  55:     <role-name>everyone</role-name>
  56:   </security-role>
  57:
  58:   <method-permission>
  59:     <role-name>everyone</role-name>
  60:     <method>
  61:       <ejb-name>CabinEJB</ejb-name>
  62:       <method-name>*</method-name>
  63:     </method>
  64:     <method>
  65:       <ejb-name>TravelAgentEJB</ejb-name>
  66:       <method-name>*</method-name>
  67:     </method>
  68:   </method-permission>
  69:
  70:   <container-transaction>
  71:     <method>
  72:       <ejb-name>CabinEJB</ejb-name>
  73:       <method-name>*</method-name>
  74:     </method>
  75:     <method>
  76:        <ejb-name>TravelAgentEJB</ejb-name>
  77:        <method-name>*</method-name>
  78:     </method>
  79:     <trans-attribute>Required</trans-attribute>
  80:   </container-transaction>
  81:
  82: </assembly-descriptor>
  83:
  84:</ejb-jar>


Existen 2 maneras de cambiar la base (en HSQL) por defecto de JBoss a MySQL:

1. Sustituyendo el "DefaultDS" para que apunte ahora a una base en MySQL
1. mysql-ds.xml
   • Copiar el archivo mysql-ds.xml localizado en [JBOSS_HOME]/docs/examples/jca al folder de deploy.
   • Modificarlo de manera que contenga los parametros de la base de datos para jboss (jbossdb en nuestro ejemplo) así como el nuevo nombre del data source:

       <jndi-name>DefaultDS</jndi-name>
       <connection-url>jdbc:mysql://localhost:9097/jbossdb</connection-url>
       <driver-class>com.mysql.jdbc.Driver</driver-class>
       <user-name>root</user-name>
       <password>lolo</password>

   • Eliminar el archivo hsqldb-ds.xml del directorio deploy.




2. standardjaws.xml
• Editar el archivo para cambiar el tipo de mapeo del datasource de Hypersonic SQL a mySQL.

<datasource>java:/DefaultDS</datasource>

<type-mapping>mySQL</type-mapping>

3. JMS configuration descriptors
   • Eliminar el archivo hsqldb-jdbc2-service.xml del directorio deploy/jms.
   • Copiar el archivo mysql-jdbc2-service.xml del folder docs/example/jms al deploy/jms.
   • Editar el archivo mysql-jdbc2-service.xml y cambiar el datasource.

<mbean code="org.jboss.mq.pm.jdbc2.PersistenceManager"
               name="jboss.mq:service=PersistenceManager">
               <depends optional-attribute-name="ConnectionManager">jboss.jca:service=DataSourceBinding,name=DefaultDS</depends>
               <attribute name="SqlProperties">

4. Instalar MySQL Java Connector, bajar el driver de MySQL y copiarlo al directorio lib del servidor.

---



2. Creando un nuevo datasource ej: "MySqlDS"
1. mysql-ds.xml
   • Copiar el archivo mysql-ds.xml localizado en [JBOSS_HOME]/docs/examples/jca al folder de deploy.
   • Modificarlo de manera que contenga los parametros de la base de datos para jboss (jbossdb en nuestro ejemplo) así como el nuevo nombre del data source:

       <jndi-name>MySqlDS</jndi-name>
       <connection-url>jdbc:mysql://localhost:9097/jbossdb</connection-url>
       <driver-class>com.mysql.jdbc.Driver</driver-class>
       <user-name>root</user-name>
       <password>lolo</password>

   • Eliminar el archivo hsqldb-ds.xml del directorio deploy.

2. ejb-deployer.xml
• Modificar el archivo de manera que emplee el Datasource de MySQL

        <!-- A persistence policy that persistes timers to a database -->
         <mbean code="org.jboss.ejb.txtimer.DatabasePersistencePolicy"
                name="jboss.ejb:service=EJBTimerService,persistencePolicy=database">
         <!-- DataSource JNDI name -->
         <depends optional-attribute-name="DataSource">jboss.jca:service=DataSourceBinding,name=MySqlDS</depends>
         <!-- The plugin that handles database persistence -->
         <attribute name="DatabasePersistencePlugin">org.jboss.ejb.txtimer.GeneralPurposeDatabasePersistencePlugin</attribute>
         </mbean>

3. standardjaws.xml
• Editar el archivo para cambiar el tipo de mapeo del datasource de Hypersonic SQL a mySQL.

<datasource>java:/MySqlDS</datasource>

<type-mapping>mySQL</type-mapping>

4. JMS configuration descriptors
   • Eliminar el archivo hsqldb-jdbc2-service.xml del directorio deploy/jms.
   • Copiar el archivo mysql-jdbc2-service.xml del folder docs/example/jms al deploy/jms.
   • Editar el archivo mysql-jdbc2-service.xml y cambiar el datasource.

<mbean code="org.jboss.mq.pm.jdbc2.PersistenceManager"
               name="jboss.mq:service=PersistenceManager">
               <depends optional-attribute-name="ConnectionManager">jboss.jca:service=DataSourceBinding,name=MySqlDS</depends>
               <attribute name="SqlProperties">

5. Instalar MySQL Java Connector, bajar el driver de MySQL y copiarlo al directorio lib del servidor.

   1:<?xml version="1.0" encoding="UTF-8"?>
   2:
   3:<!-- $Id: mysql-ds.xml,v 1.3.2.1 2004/12/01 11:46:00 schrouf Exp $ -->
   4:<!--  Datasource config for MySQL using 3.0.9 available from:
   5:http://www.mysql.com/downloads/api-jdbc-stable.html
   6:-->
   7:
   8:<datasources>
   9:  <local-tx-datasource>
  10:    <jndi-name>IS346DS</jndi-name>
  11:    <connection-url>jdbc:mysql://localhost:9097/is346</connection-url>
  12:    <driver-class>com.mysql.jdbc.Driver</driver-class>
  13:    <user-name>root</user-name>
  14:    <password>lolo</password>
  15:    <exception-sorter-class-name>org.jboss.resource.adapter.jdbc.vendor.MySQLExceptionSorter</exception-sorter-class-name>
  16:    <!-- sql to call when connection is created
  17:    <new-connection-sql>some arbitrary sql</new-connection-sql>
  18:      -->
  19:    <!-- sql to call on an existing pooled connection when it is obtained from pool
  20:    <check-valid-connection-sql>some arbitrary sql</check-valid-connection-sql>
  21:      -->
  22:
  23:    <!-- corresponding type-mapping in the standardjbosscmp-jdbc.xml (optional) -->
  24:    <metadata>
  25:       <type-mapping>mySQL</type-mapping>
  26:    </metadata>
  27:  </local-tx-datasource>
  28:</datasources>
  29:

digital@localhost:~/mysql> ./mysql.server start
       digital@localhost:~/mysql> bin/mysql -u root -p mysql
       Enter password:
       Reading table information for completion of table and column names
       You can turn off this feature to get a quicker startup with -A

Welcome to the MySQL monitor. Commands end with ; or \g.
         Your MySQL connection id is 1 to server version: 4.1.9-max-log

Type 'help;' or '\h' for help. Type '\c' to clear the buffer.

mysql> create database jbossdb;
         Query OK, 1 row affected (0.03 sec)

mysql> create database is346;
         Query OK, 1 row affected (0.03 sec)

digital@localhost:~/jboss/bin> ./run.sh
=========================================================================

 JBoss Bootstrap Environment

 JBOSS_HOME: /home/digital/jboss

 JAVA: /opt/java/j2sdk/bin/java

 JAVA_OPTS: -server -Xms128m -Xmx128m -Dprogram.name=run.sh

 CLASSPATH: /home/digital/jboss/bin/run.jar:/opt/java/j2sdk/lib/tools.jar

=========================================================================

11:36:16,161 INFO [Server] Starting JBoss (MX MicroKernel)...
         11:36:16,163 INFO [Server] Release ID: JBoss [Zion] 4.0.1sp1 (build: CVSTag=JBoss_4_0_1_SP1          date=200502160314)
         11:36:16,164 INFO [Server] Home Dir: /home/digital/jboss
         11:36:16,165 INFO [Server] Home URL: file:/home/digital/jboss/
         11:36:16,165 INFO [Server] Library URL: file:/home/digital/jboss/lib/
         11:36:16,167 INFO [Server] Patch URL: null
         11:36:16,168 INFO [Server] Server Name: default
         11:36:16,168 INFO [Server] Server Home Dir: /home/digital/jboss/server/default
         11:36:16,169 INFO [Server] Server Home URL: file:/home/digital/jboss/server/default/
         11:36:16,170 INFO [Server] Server Data Dir: /home/digital/jboss/server/default/data
         11:36:16,171 INFO [Server] Server Temp Dir: /home/digital/jboss/server/default/tmp
         11:36:16,171 INFO [Server] Server Config URL: file:/home/digital/jboss/server/default/conf/
         11:36:16,172 INFO [Server] Server Library URL: file:/home/digital/jboss/server/default/lib/
         11:36:16,172 INFO [Server] Root Deployment Filename: jboss-service.xml
         11:36:16,178 INFO [Server] Starting General Purpose Architecture (GPA)...
         11:36:17,286 INFO [ServerInfo] Java version: 1.4.2_07,Sun Microsystems          Inc.
         11:36:17,286 INFO [ServerInfo] Java VM: Java HotSpot(TM) Server VM 1.4.2_07-b05,Sun          Microsystems Inc.
         11:36:17,287 INFO [ServerInfo] OS-System: Linux 2.6.8-24.11-default,i386
         11:36:18,431 INFO [Server] Core system initialized
         11:36:24,833 INFO [Log4jService$URLWatchTimerTask] Configuring from URL:          resource:log4j.xml
         11:36:25,177 INFO [WebService] Using RMI server codebase: http://localhost:8083/
         11:36:25,727 INFO [NamingService] Started jndi bootstrap jnpPort=1099,          rmiPort=1098, backlog=50, bindAddress=/0.0.0.0, Client SocketFactory=null,          Server SocketFactory=org.jboss.net.sockets.DefaultSocketFactory@ad093076
         11:36:40,597 INFO [Embedded] Catalina naming disabled
         11:36:43,591 INFO [Http11Protocol] Initializing Coyote HTTP/1.1 on http-0.0.0.0-8080
         11:36:43,794 INFO [Catalina] Initialization processed in 2749 ms
         11:36:43,795 INFO [StandardService] Starting service jboss.web
         11:36:43,802 INFO [StandardEngine] Starting Servlet Engine: Apache Tomcat/5.0.28
         11:36:43,943 INFO [StandardHost] XML validation disabled
         11:36:43,999 INFO [Catalina] Server startup in 204 ms
         11:36:44,623 INFO [TomcatDeployer] deploy, ctxPath=/invoker, warUrl=file:/home/digital/jboss/server/default/deploy/http-invoker.sar/invoker.war/
         11:36:47,823 INFO [TomcatDeployer] deploy, ctxPath=/ws4ee, warUrl=file:/home/digital/jboss/server/default/tmp/deploy/tmp16173jboss-ws4ee.war/
         11:36:48,471 INFO [TomcatDeployer] deploy, ctxPath=/, warUrl=file:/home/digital/jboss/server/default/deploy/jbossweb-tomcat50.sar/ROOT.war/
         11:36:49,310 INFO [TomcatDeployer] deploy, ctxPath=/jbossmq-httpil, warUrl=file:/home/digital/jboss/server/default/deploy/jms/jbossmq-httpil.sar/jbossmq-httpil.war/
         11:36:58,781 INFO [MailService] Mail Service bound to java:/Mail
         11:37:01,354 INFO [RARDeployment] Required license terms exist view the          META-INF/ra.xml: file:/home/digital/jboss/server/default/deploy/jboss-local-jdbc.rar
         11:37:02,078 INFO [RARDeployment] Required license terms exist view the          META-INF/ra.xml: file:/home/digital/jboss/server/default/deploy/jboss-xa-jdbc.rar
         11:37:02,750 INFO [RARDeployment] Required license terms exist view the          META-INF/ra.xml: file:/home/digital/jboss/server/default/deploy/jms/jms-ra.rar
         11:37:03,461 INFO [RARDeployment] Required license terms exist view the          META-INF/ra.xml: file:/home/digital/jboss/server/default/deploy/mail-ra.rar
         11:37:05,175 INFO [WrapperDataSourceService] Bound connection factory          for resource adapter for ConnectionManager 'jboss.jca:name=IS346DS,service=DataSourceBinding          to JNDI name 'java:IS346DS'
         11:37:06,642 INFO [ConnectionFactoryBindingService] Bound connection factory          for resource adapter for ConnectionManager 'jboss.jca:name=JmsXA,service=ConnectionFactoryBinding          to JNDI name 'java:JmsXA'
         11:37:07,336 INFO [WrapperDataSourceService] Bound connection factory          for resource adapter for ConnectionManager 'jboss.jca:name=MySqlDS,service=DataSourceBinding          to JNDI name 'java:MySqlDS'
         11:37:10,718 INFO [TomcatDeployer] deploy, ctxPath=/jmx-console, warUrl=file:/home/digital/jboss/server/default/deploy/jmx-console.war/
         11:37:11,581 INFO [TomcatDeployer] deploy, ctxPath=/web-console, warUrl=file:/home/digital/jboss/server/default/deploy/management/web-console.war/
         11:37:14,320 ERROR [URLDeploymentScanner] Incomplete Deployment listing:
         MBeans waiting for other MBeans:
         ObjectName: jboss.mq:service=InvocationLayer,type=HTTP
         state: CONFIGURED
         I Depend On: jboss.mq:service=Invoker
         jboss.web:service=WebServer

 Depends On Me:
         ObjectName: jboss:service=KeyGeneratorFactory,type=HiLo
         state: CONFIGURED
         I Depend On: jboss:service=TransactionManager
         jboss.jca:name=DefaultDS,service=DataSourceBinding

 Depends On Me:
         ObjectName: jboss.mq:service=StateManager
         state: CONFIGURED
         I Depend On: jboss.jca:name=DefaultDS,service=DataSourceBinding

 Depends On Me: jboss.mq:service=DestinationManager

ObjectName: jboss.mq.destination:name=testTopic,service=Topic
         state: CONFIGURED
         I Depend On: jboss.mq:service=DestinationManager
         jboss.mq:service=SecurityManager

 Depends On Me:
         ObjectName: jboss.mq.destination:name=securedTopic,service=Topic
         state: CONFIGURED
         I Depend On: jboss.mq:service=DestinationManager
         jboss.mq:service=SecurityManager

 Depends On Me:
         ObjectName: jboss.mq.destination:name=testDurableTopic,service=Topic
         state: CONFIGURED
         I Depend On: jboss.mq:service=DestinationManager
         jboss.mq:service=SecurityManager

 Depends On Me:
         ObjectName: jboss.mq.destination:name=testQueue,service=Queue
         state: CONFIGURED
         I Depend On: jboss.mq:service=DestinationManager
         jboss.mq:service=SecurityManager

 Depends On Me:
         ObjectName: jboss.mq.destination:name=A,service=Queue
         state: CONFIGURED
         I Depend On: jboss.mq:service=DestinationManager

 Depends On Me:
         ObjectName: jboss.mq.destination:name=B,service=Queue
         state: CONFIGURED
         I Depend On: jboss.mq:service=DestinationManager

 Depends On Me:
         ObjectName: jboss.mq.destination:name=C,service=Queue
         state: CONFIGURED
         I Depend On: jboss.mq:service=DestinationManager

 Depends On Me:
         ObjectName: jboss.mq.destination:name=D,service=Queue
         state: CONFIGURED
         I Depend On: jboss.mq:service=DestinationManager

 Depends On Me:
         ObjectName: jboss.mq.destination:name=ex,service=Queue
         state: CONFIGURED
         I Depend On: jboss.mq:service=DestinationManager

 Depends On Me:
         ObjectName: jboss.mq:service=Invoker
         state: CONFIGURED
         I Depend On: jboss.mq:service=TracingInterceptor

 Depends On Me: jboss.mq:service=InvocationLayer,type=HTTP
         jboss.mq:service=InvocationLayer,type=JVM
         jboss.mq:service=InvocationLayer,type=UIL2

ObjectName: jboss.mq:service=TracingInterceptor
         state: CONFIGURED
         I Depend On: jboss.mq:service=SecurityManager

 Depends On Me: jboss.mq:service=Invoker

ObjectName: jboss.mq:service=SecurityManager
         state: CONFIGURED
         I Depend On: jboss.mq:service=DestinationManager

 Depends On Me: jboss.mq.destination:name=testTopic,service=Topic
         jboss.mq.destination:name=securedTopic,service=Topic
         jboss.mq.destination:name=testDurableTopic,service=Topic
         jboss.mq.destination:name=testQueue,service=Queue
         jboss.mq:service=TracingInterceptor
         jboss.mq.destination:name=DLQ,service=Queue

ObjectName: jboss.mq.destination:name=DLQ,service=Queue
         state: CONFIGURED
         I Depend On: jboss.mq:service=DestinationManager
         jboss.mq:service=SecurityManager

 Depends On Me:
         ObjectName: jboss.mq:service=InvocationLayer,type=JVM
         state: CONFIGURED
         I Depend On: jboss.mq:service=Invoker

 Depends On Me:
         ObjectName: jboss.mq:service=DestinationManager
         state: CONFIGURED
         I Depend On: jboss.mq:service=MessageCache
         jboss.mq:service=PersistenceManager
         jboss.mq:service=StateManager

 Depends On Me: jboss.mq.destination:name=testTopic,service=Topic
         jboss.mq.destination:name=securedTopic,service=Topic
         jboss.mq.destination:name=testDurableTopic,service=Topic
         jboss.mq.destination:name=testQueue,service=Queue
         jboss.mq.destination:name=A,service=Queue
         jboss.mq.destination:name=B,service=Queue
         jboss.mq.destination:name=C,service=Queue
         jboss.mq.destination:name=D,service=Queue
         jboss.mq.destination:name=ex,service=Queue
         jboss.mq:service=SecurityManager
         jboss.mq.destination:name=DLQ,service=Queue

ObjectName: jboss.mq:service=InvocationLayer,type=UIL2
         state: CONFIGURED
         I Depend On: jboss.mq:service=Invoker

 Depends On Me:

MBEANS THAT ARE THE ROOT CAUSE OF THE PROBLEM:
         ObjectName: jboss.jca:name=DefaultDS,service=DataSourceBinding
         state: NOTYETINSTALLED
         I Depend On:
         Depends On Me: jboss:service=KeyGeneratorFactory,type=HiLo
         jboss.mq:service=StateManager

         11:37:14,908 INFO [Http11Protocol] Starting Coyote HTTP/1.1 on http-0.0.0.0-8080
         11:37:15,243 INFO [ChannelSocket] JK2: ajp13 listening on /0.0.0.0:8009
         11:37:15,253 INFO [JkMain] Jk running ID=0 time=0/108 config=null
         11:37:15,319 INFO [Server] JBoss (MX MicroKernel) [4.0.1sp1 (build: CVSTag=JBoss_4_0_1_SP1          date=200502160314)] Started in58s:610ms


mysql> use jbossdb;
Database changed
mysql> show tables;
+-------------------+
| Tables_in_jbossdb |
+-------------------+
| JMS_MESSAGES      |
| JMS_TRANSACTIONS  |
| TIMERS            |
+-------------------+
3 rows in set (0.00 sec)

mysql>

Archivos generados

EJB QL Examples

SELECT DISTINCT OBJECT(p)
FROM Player p
WHERE p.position = ?1

Data retrieved: The players with the position specified by the finder method's parameter.

SELECT DISTINCT OBJECT(p)
FROM Player p
WHERE p.position = ?1 AND p.name = ?2

Data retrieved: The players with the specified position and name.

SELECT DISTINCT OBJECT(p)
FROM Player p
WHERE p.salary BETWEEN ?1 AND ?2

Data retrieved: The players whose salaries fall within the range of the specified salaries. ?

SELECT DISTINCT OBJECT(p)
FROM Player p, IN (p.teams) AS t
WHERE t.city = ?1

Data retrieved: The players whose teams belong to the specified city.

SELECT DISTINCT OBJECT(p)
FROM Player p, IN (p.teams) AS t
WHERE t.league.sport = ?1

Data retrieved: The players who participate in the specified sport.

Where Operators

...BETWEEN 8 AND 16

....Address.state IN ('FL','TX',?1)
NOT IN (similar al IN)

...IS NULL ....IS NOT NULL

...crs.reservations IS NOT EMPTY

..phone.number LIKE '222%'
Cuidado, no se pueden usar "input parameters" con LIKE, esto NO es válido
..phone.number LIKE '% ?1 %'

Functional Expressions

CONCAT(String1, String2)

LENGTH(String)

LOCATE(String1, String2 [,start])

SUBSTRING(String1, start, length)

ABS(number)

SQRT(double)

MOD(int,int)

Aggregate functions (select)

COUNT(identifier or path expression)

MAX(path expresssion), MIN (path expression)

AVG(numeric), SUM(numeric)
